Specification
- Speaker Type Standmount
- UOM (Sold As) Pair
TRANSDUCER
- Tweeter 1" Pinnacle Ring Radiator
- Mid-range/Mid-bass -
- Woofers 6 ½” Turbine Cone
- Overall Frequency Response 39Hz - 50kHz
- Frequency Response (-3dB limits) 51Hz - 38kHz
- Recommended Amplifier Power 30 - 200W
- Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
- Minimum Impedance (ohms) 3.8Ω
- Sensitivity (2.83V/1m) 86dB
- Tweeter 1" Pinnacle Ring Radiator
- Mid-range/Mid-bass -
- Woofers 6 ½” Turbine Cone
- Overall Frequency Response 39Hz - 50kHz
- Frequency Response (-3dB limits) 51Hz - 38kHz
- Recommended Amplifier Power 30 - 200W
- Amplifier Output Compatibility 8Ω / 6Ω / 4Ω
- Minimum Impedance (ohms) 3.8Ω
- Sensitivity (2.83V/1m) 86dB
CROSSOVER
- Tweeter/Mid-range Crossover Frequency 3000 Hz
- Mid-range/Mid-bass Crossover Frequency -
MEASUREMENTS
-
Product Dimensions W x H x D (Includes width of feet)
7.5 x 14.1 x 13.9 in
190 x 359 x 353.8mm - Product Weight (each) 19.1 lbs/8.7 kg
- Shipping Weight 43.4 lbs/19.7 kg
-
Shipping Dimensions (WxHxD)
21 x 17.6 x 17.8 in
533 x 448 x 452mm -
Product Dims W x H x D (Includes width of feet)
190 x 359 x 353.8mm
7.5 x 14.1 x 13.9 in - Product Weight (each) 19.1 lbs/8.7 kg
- Shipping Weight 43.4 lbs/19.7 kg
CABINETRY
- New CRC (Mid-Range Enclosure Type) -
- Mid-Bass / Woofer Enclosure Type Rear X-Port
- Available Finishes Cherry Wood
- Feet Rubber pads
- Wall-Mountable (keyhole slots) No
- Binding Posts: 24k Gold-plated 5-Way Single
- Binding Posts: Nickel-plated 5-Way Single
- Available Finishes Black / Walnut / White
Certifications Non-Safety and Regulatory
- Hi-Res Certified Yes
- IMAX Certified No
-
Shipping Dims (WxHxD)
533 x 448 x 452mm
(21 x 17.6 x 17.8) in
